:: Forums › My E30 in making ...........

-> Lansi Gallery

#76: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:24 am
----

Finally car is lowered and doing the alignment................

#77: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:25 am
----

Exhaust time .............Super Sprint for E46 318 .......

Main reason decided for E46 version cos its newer so condition is better and maybe better technology as well.......

But some modification needed to fit it to E30 ...Thanks to Kingston from Everco who did a good job to complete the modification ........

#78: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:25 am
----

1st step ........removed the original bac kbox............

2nd ......cut the exhaust tips ........

The tips .......

Clean up the back box .......

3rd steps.........Trying to install the back box to my car ......Need to modified the bracket ........

#79: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:27 am
----

After the back box done .....Found out some leaking at the front portion of the exhaust due to bent bracket as u can see in the pics.......Its cause uneven surface and cause the air leaking even with new gasket.........

So decided to change the center portion using Everco product and as u can see in the pic, the bracket is much thicker ..............

All done ................

The Super Sprint is just too nice ..........

Love it ..........

#80: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:28 am
----

4th steps .......Extension to connect the exhaust tips to the back box............

Result .....yummmyyyy.............

#81: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:28 am
----
Some latest update ...........

Doing some mod to improve the handling .......

Custom Aluminium Guibo .............

The left is the custom aluminium guibo compared with OEM rubber type .......

How the thing look like after installed ...............

The result is very impressive as E30 steering is a bit loose/free play ....but with the aluminium guibo ......its more rigid and tie ......

Must do for E30.........

#82: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:29 am
----

Changing the wind screen with the rubber moulding ......

Found a original used from a frend who run a chop shop............

#83: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:30 am
----
Custom made heat shield ............heheheh

1st ....u must find a pipe which can suit ur open pot size and cut to the size tat can suit ut engine based ........

U need at least 3 screws to hold the filter to the pipe .......Make sure the screw is not hit the filter paper ........

How the heat shield looks after the thing done .........

Some domestic job ...........wrap wit a cheap carbon looks a like sticker to make it looks nicer and the job done ...........

#84: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:31 am
----
Latest mod ...............

Not really like the height of Bilstein spring so decided go for H&R spring instead ..............

H&R on ....................

Result is just PERFECT ................

I luv the height of my E30 now ......

Tested the car and the handling is just nice ......

Luv it .............

#85: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:31 am
----
Finally found the item i want ......Took me lot of time to find it ........

Used original cover for bottom of driver side ........

Very good condition indeed .....

Got it at very reasonable price ................

#86: Re: My E30 in making ........... Author: lionel,

Posted: Mon Jan 18, 2010 8:32 am
----
How about this 16 inch rim ???????

Condition before polishing.................

Result after 1 stage polishing ................

#87: Re: My E30 in making ........... Author: jeembo, Location: Car_Junk

Posted: Mon Jan 18, 2010 10:11 am
----
hotness!

#88: Re: My E30 in making ........... Author: Mr_Bimmerasta, Location: The Republic Of Penang

Posted: Mon Jan 18, 2010 10:32 am
----
Fuh...marvelous! Silau mata la lu punya BBS..!

#89: Re: My E30 in making ........... Author: kura2,

Posted: Mon Jan 18, 2010 11:22 am
----
liked the heatshield idea! habis la paip jiran aku mlm ni hahaha.

#90: Re: My E30 in making ........... Author: highwaystar, Location: Kola Lompuer

Posted: Mon Jan 18, 2010 1:02 pm
----
Thank you for sharing lionel.
Truly awesome especially the exhaust box. Oops, kinda worried about the heatsheild, the idea is good but to use PVC for heat kinda bad idea, easy to lembik, but can try oso since M40 engine space memang banyak, therefore heat travel much on freeflow rather than M20.

mmmm kinda interested on the guibo wonder how much will cost me to do that... care to share? cheers!
